eneo Network cameras

Further protocols; DHCP, NTP, UPnP, Telnet, FTP. The new thermal imaging cameras in the Candid series give users the triple advantage of maintenance-free thermal imaging technology, multifunctional Candid design and complete system flexibility due to analog and IP connectivity. Each model also has a USB port. And just the same as all eneo IP cameras, Candid thermal imaging cameras are fully compatible with Aimetis software products. Candid thermal imaging cameras come with a three-year warranty. And because they are equipped with uncooled thermal imaging modules, they can work maintenance-free for years.

Thick fog? Complete darkness? Long distances? No problem. The new Candid thermal imaging cameras always give you a clear picture of the situation with detection ranges up to 3,800 metres. The camera includes Candid ease of installation and application possibilities beyond classic video surveillance. The new Candid thermal imaging cameras are offered in different versions with focal lengths of 5 mm, 7,5 mm, 9 mm, 13 mm, 19 mm, 25 mm and 35 mm. A total of 32 different models are available. Their sturdy housing (IP67) ensures they are ideal for use in harsh environments with temperatures from -35 to 50°C. And detection ranges from 330 to 3,800 metres make them specialists for area surveillance and perimeter protection. This allows them to identify potential intruders from a long distance, even in fog, rain, snow and smoke – regardless of the ambient light. The new thermal imaging cameras in the Candid series give users the triple advantage of maintenance-free thermal imaging technology, multifunctional Candid design and complete system flexibility due to analogue and IP connectivity. Each model also has a USB port. And just the same as all eneo IP cameras, Candid thermal imaging cameras are fully compatible with Aimetis software products. Candid thermal imaging cameras come with a three-year warranty. And because they are equipped with uncooled thermal imaging modules, they can work maintenance-free for years.

*Further protocols: DHCP, NTP, UPnP, Telnet, FTP. The new thermal imaging cameras in the Candid series give users the triple advantage of maintenance-free thermal imaging technology, multifunctional Candid design and complete system flexibility due to analogue and IP connectivity. Each model also has a USB port. And just the same as all eneo IP cameras, Candid thermal imaging cameras are fully compatible with Aimetis software products.Candid thermal imaging cameras come with a three-year warranty. And because they are equipped with uncooled thermal imaging modules, they can work maintenance-free for years.

* FTP, DHCP, UPnP, RTSP, RTP, RTCP, TCP, UDP, PPPoE.

The user-friendly IP recorders in the F Series - the FNR-4004/500 and FNR-4016/500 - make it truly easy to record over a network. Video imagery is stored using the efficient H.264 compression. The maximum recording speed per channel is 25 frames per second. The resolution, frame rate, bit rate, picture quality etc. can be set separately for each video channel and configured optimally to the site conditions. This therefore allows the best possible setting for, for instance, surveillance over a large area with many details (railway station platforms, public areas, etc.) so that details are clearly recognisable with digital zooming into the picture as required. On the other hand, a lower picture quality, resolution, etc. can be set to reduce network load and memory requirements when surveillance merely has to detect movement in the monitored area. This is also supported by dual video streams: this function allows simultaneous transmission of video imagery from one channel over two video streams that can also be configured -to match the end device for instance (monitor or smartphone). The FNR-4016/500 has 16 channels, the FNR-4004/500 four. Up to eight SATA hard disks can be installed in the FNR-4016 housing to achieve very large storage capacities. The FNR-4016 has 16 alarm inputs and eight alarm outputs, the FNR-4004 has four alarm inputs and one alarm output. Further functions include the digital zoom to allow zooming in on relevant details at the click of a mouse for live pictures or during playback, two USB ports for user-friendly data export, integrated motion detector for each channel, extensive options for user management, PTZ control of connected pan/tilt systems (RS-485), pre- and post-alarm recording and privacy masking, that masks out image areas not to be covered by surveillance, such as windows in a residential building. So much for the common features - but what, in addition to the different channel number, are the differences? The most important difference lies in support to different manufacturers: whilst the FNR-4004/500 is ideal purely for eneo products (F Series, N and G Series currently under development), the FNR-4016/500 also supports products from Axis, Bosch, Panasonic, Sanyo and Sony, so that extra flexibility is provided for product selection during system planning and installation as well as upgrades.

* DSCP, UPnP, RTSP, RTP, TCP, UDP, NTP.

*RTP, RTCP, RTSP, 3GPP, NTP, DNS, DDNS, PPPoE, UPnP, SAMBA, FTP, SMTP

The new eneo hybrid thermal imaging cameras are specialists for area surveillance and perimeter protection, because they capture the thermal signature of an object or body invisible to the human eye which allows them to identify potential intruders from a long distance, even in fog, rain, snow and smoke – regardless of the ambient light. Numerous entry-level models with analogue and IP connectivity and different focal lenghts eneo thermal imaging cameras come in a Candid Medium bullet housing as practical as it is elegant with IP67 protection and designed for fast plug & play installation. These are uncooled thermal imaging systems – the best economical solution wherever objects are to be detected at a maximum distance of 4 km. As opposed to cooled systems designed for much longer distances, uncooled thermal camera modules can operate maintenance-free over many years. They are available with a choice of 5 mm, 9 mm, 13 mm, 19 mm, 25 mm and 35 mm focal lengths with ranges from 330 to 4050 metres. Their thermal sensitivity lies at 50 millikelvin at an ambient temperature of 25°C. There is no technology system question with eneo thermal cameras as they have analogue as well as IP connectivity. By the way, connectivity: each module also has an external USB port.

* FTP, DHCP, UPnP, RTSP, RTP, RTCP, TCP, UDP, PPPoE.

* UPnP, RTSP, RTP, TCP, UDP, NTP.

* DSCP, UPnP, RTSP, RTP, TCP, UDP, NTP.

1/2.7" CMOS-Sensor Resolution max. 5MP, 30 fps IR LED illumination AI analysis functions including object classification Colour images in the dark due to integrated white light Smart Codec H.265/H.264, Multi-streaming Motorised varifocal lens 2.8 - 12mm Noise Reduction (3D-DNR), WDR 120dB Local storage via Micro SD card Supports ONVIF profiles S and T PoE IEEE802.3af Supports audio and external alarm input and output Browser independent (IE, Edge, Safari, Firefox, Chrome) IP67

1/2.7" CMOS-Sensor Resolution max. 5MP, 30 fps IR LED illumination AI analysis functions including object classification Smart Codec H.265/H.264, Multi-streaming Motorised varifocal lens 2.7 - 13.5mm Noise Reduction (3D-DNR), WDR 120dB Local storage via Micro SD card Supports ONVIF profiles S and T PoE IEEE802.3af Supports audio and external alarm input and output Multilingual menu navigation (OSD) Browser independent (IE, Edge, Safari, Firefox, Chrome) IP67

1/2.8" Sony STARVIS CMOS-Sensor Resolution max. 8MP, 30 fps IR LED illumination AI analysis functions including object classification Colour images in the dark due to integrated white light Smart Codec H.265/H.264, Multi-streaming Motorised varifocal lens 2.8 - 12mm Noise Reduction (3D-DNR), WDR 120dB Local storage via Micro SD card Supports ONVIF profiles S and T PoE IEEE802.3af Supports audio and external alarm input and output Browser independent (IE, Edge, Safari, Firefox, Chrome) IP67

1/2.8" Sony STARVIS CMOS-Sensor Resolution max. 8MP, 30 fps IR LED illumination AI analysis functions including object classification Smart Codec H.265/H.264, Multi-streaming Motorised varifocal lens 2.7 - 13.5mm Noise Reduction (3D-DNR), WDR 120dB Local storage via Micro SD card Supports ONVIF profiles S and T PoE IEEE802.3af Supports audio and external alarm input and output Multilingual menu navigation (OSD) Browser independent (IE, Edge, Safari, Firefox, Chrome) IP67

1/2.3" Omnivision CMOS sensor Maximum resolution 4000x3000 @ 15fps Day/night function, 3D-DNR, slow speed shutter 1.6mm fixed focal length, Fisheye lens 360° panoramic, quad, panomorphic view D-WDR (Digital Wide Dynamic Range) Smart Codec H.265/H.264, multi-streaming Triple stream (main, sub, mobile) IR LED illumination Browser independent (Edge, Safari, Firefox, Chrome) Supports ONVIF profiles S/T/G Loudspeaker and microphone integrated Integration with eneo INsight software & App For indoor and outdoor use

1/2.7" SmartSens CMOS sensor Maximum resolution 1920x1080 pixels AI analysis functions including object classification WDR 120dB, 3D-DNR noise reduction Motorised autofocus zoom lens 18x 5.0-90mm Smart Codec H.265/H.264, multi-streaming IR LED illumination Browser independent (Edge, Safari, Firefox, Chrome) Supports ONVIF profiles S/T/G PoE IEEE 802.3af Local storage via Micro SD card Audio & alarm input and output

1/2.8" Sony STARVIS CMOS sensor Maximum resolution 3840x2160 pixels AI analysis functions including object classification Colour images in the dark due to integrated white light WDR 120dB, 3D-DNR noise reduction Motorised varifocal lens 2.8-12mm Smart Codec H.265/H.264, multi-streaming IR LED illumination Browser independent (IE, Edge, Safari, Firefox, Chrome) Supports ONVIF profiles S/T Supports audio and external alarm input and output Local storage via Micro SD card

1/2.7" CMOS sensor 5 MP / 30 fps AI analysis functions including object classification Colour images in the dark due to integrated white light WDR 120dB, 3D-DNR noise reduction Motorised varifocal lens 2.8-12mm Smart Codec H.265/H.264, multi-streaming IR LED illumination Browser independent (IE, Edge, Safari, Firefox, Chrome) Supports ONVIF profiles S/T Supports audio and external alarm input and output Local storage via Micro SD card

1/2.7" CMOS sensor 5 MP / 30 fps AI analysis functions including object classification WDR 120dB, 3D-DNR noise reduction Motorised varifocal lens 2.7-13.5mm Smart Codec H.265/H.264, multi-streaming IR LED illumination Browser independent (IE, Edge, Safari, Firefox, Chrome) Supports ONVIF profiles S/T Supports audio and external alarm input and output Local storage via Micro SD card Multilingual menu navigation (OSD)

1/2.8" Sony STARVIS CMOS sensor 2 MP / 60 fps AI analysis functions including object classification WDR 120dB, 3D-DNR noise reduction Motorised varifocal lens 2.8-12mm Smart Codec H.265/H.264, multi-streaming IR LED illumination Browser independent (IE, Edge, Safari, Firefox, Chrome) Supports ONVIF profiles S/T Supports audio and external alarm input and output Local storage via Micro SD card Multilingual menu navigation (OSD)

Eneo PXB-1080Z03 day&night network camera with auto focus zoom and IR-LED.

1/2.8" Sony STARVIS CMOS sensor 8 MP / 30 fps AI analysis functions including object classification WDR 120dB, 3D-DNR noise reduction Motorised varifocal lens 2.7-13.5mm Smart Codec H.265/H.264, multi-streaming IR LED illumination Browser independent (IE, Edge, Safari, Firefox, Chrome) Supports ONVIF profiles S/T Supports audio and external alarm input and output Local storage via Micro SD card Multilingual menu navigation (OSD)

1/2.8" Sony STARVIS CMOS sensor 2 MP / 60 fps AI analysis functions including object classification WDR 120dB, 3D-DNR noise reduction Motorised varifocal lens 2.8-8mm Smart Codec H.265/H.264, multi-streaming IR LED illumination Browser independent (IE, Edge, Safari, Firefox, Chrome) Supports ONVIF profiles S/T Supports audio and external alarm input and output Local storage via Micro SD card Multilingual menu navigation (OSD)

1/2.7" CMOS sensor Maximum resolution 2592x1944 pixels AI analysis functions including object classification WDR 120dB, 3D-DNR noise reduction Motorised autofocus zoom lens 33x 4.3-142mm Smart Codec H.265/H.264, multi-streaming IR LED illumination Browser independent (IE, Edge, Safari, Firefox, Chrome) Supports ONVIF profiles S/T PoE IEEE 802.3af Local storage via Micro SD card Audio input and output

1/2.8" Sony STARVIS CMOS-Sensor Resolution max. 2MP, 60 fps IR LED illumination AI analysis functions including object classification Smart Codec H.265/H.264, Multi-streaming Motorised varifocal lens 2.8 - 12mm Noise Reduction (3D-DNR), WDR 120dB Local storage via Micro SD card Supports ONVIF profiles S and T PoE IEEE802.3af Supports audio and external alarm input and output Multilingual menu navigation (OSD) Browser independent (IE, Edge, Safari, Firefox, Chrome) IP67

1/2.7" Omnivision CMOS-Sensor Resolution max. 2592x1944, 30 fps IR LED illumination AI analysis functions including object classification Smart Codec H.265/H.264, Multi-streaming Motorised varifocal lens 5.0 - 50mm Noise Reduction (3D-DNR), WDR 120dB Local storage via Micro SD card Supports ONVIF profiles S/T/G PoE IEEE802.3af Supports audio and external alarm input and output Browser independent (Edge, Safari, Firefox, Chrome) IP67
