CEM Security management

CEM emerald TS100 intelligent access terminal has a large internal encrypted database that enables it to operate in off-line mode. It also has PIR motion detection as well as supports a range of smart card technologies.

CEM RDR/610/105 MiFare card reader designed for use as part of an integrated on-line access control system and is used to control access to restricted areas or in special applications where card activation of machinery is required. It also features large reader database for off-line card verification and alarms.

CEM CRD/229/004 DESFire 13.56MHz read/write contactless smart card can be used for a range of different applications from access control to other applications such as cashless vending and public transportation. Using a standardised Mifare Application Directory (MAD), the card contains a structured file system offering security for multiple applications and to support future growth. Utilising Advanced Encryption Standard (AES) -128-bit encryption, the information is securely stored on the card, ensuring that it cannot be cloned and that only valid cards are granted access.

CEM RDR/612/119 is an exit card reader with PIN designed for use as part of an integrated on-line access control system. The Exit Reader is an extension to the master reader, providing a combined total of features at the point of entry. It communicates directly with the master reader.

CEM DCM/350/101 is a two door intelligent encrypted IP controller designed to interface to CEM sPass DESFire smart card readers. It has an on-board 10/100 Ethernet connection and communicates directly with the AC2000 server. It also features enclosure, board & power supply/battery charger.

CEM RDR/612/688 is an exit card reader with PIN designed for use as part of an integrated on-line access control system. The Exit Reader is an extension to the master reader, providing a combined total of features at the point of entry. It communicates directly with the master reader.

CEM SYS/601/064 is an AC2000 Lite Software Only Virtual Kit 64 door licence. It allows users to run the complete AC2000 Lite access control system within a virtual environment, running on a Windows 7 PC.

CEM SYS/601/128 is an AC2000 Lite Software Only Virtual Kit 128 door licence. It allows users to run the complete AC2000 Lite access control system within a virtual environment, running on a Windows 7 PC

CEM SWVINT-MOBO AC2000 Mobotix interface provides the ability to associate access control alarms with Mobotix digital video clips. This enables AC2000 to act as the central Security Management System. The video interface seamlessly integrates AC2000 with Mobotix cameras, giving the operator a range of video imaging facilities to generate alarm reports with recorded video playback. The interface also allows system operators to view live video feed and control the camera’s view and run presets.

CEM SWNVR-IV AC2000 IndigoVision NVR interface provides the ability to associate access control alarms with IndigoVision NVR digital video clips. This enables AC2000 to act as the central Security Management System. The AC2000 DVR Viewer module seamlessly integrates AC2000 with IndigoVision NVR, giving the operator a range of video imaging facilities to generate alarm reports with recorded video playback. The interface also allows system operators to view live video feed and control camera positioning. The system allows a user to fully integrate the power of a IndigoVision NVR video system into the central AC2000 Alarm Event Display (AED) application. AED enables all alarms, events and associated camera footage to be displayed centrally on the AC2000 system.

CEM SWHDVR-AD AC2000 American Dynamics HDVR interface provides the ability to associate access control alarms with digital video clips and to view live camera footage. This enables AC2000 to act as the central Security Management System. The AC2000 Video Configuration module seamlessly integrates AC2000 with the HDVR, giving the operator a range of facilities to generate alarm reports with recorded video playback. The high level two-way interface allows a user to fully integrate the power of an American Dynamics HDVR video system into the central AC2000 AED (Alarm and Event Display) application.

CEM DESFire contactless smart card comes with blank and unused memory keys that can be used for other applications. It also comes with a flexible filing system based on applications and files contained witthin the applications.

CEM SWNVR-EX AC2000 exacqVision interface enables AC2000 to act as a flexible and fully integrated Security Management System. It provides the ability to define video alarm actions, view live footage as alarms occur and control cameras and run camera presets. The AC2000 DVR Video Configuration module seamlessly integrates AC2000 with exacqVision Video Management System servers. This will give operators the ability to define video alarm actions, search alarm feeds and playback recorded video from alarms.

The CEM S610 Exit Reader features two changeover relay outputs to activate door strike or other equipment. It is also easy to install and is available with integrated reading support for 125 kHz HID Proximity, 13.56 MHz smartcard technology including DESFire, Mifare, HID iClass, and PicoPass.

CEM SYS/601/032 is an AC2000 Lite Software Only Virtual Kit 32 door licence. It allows users to run the complete AC2000 Lite access control system within a virtual environment, running on a Windows 7 PC.

CEM SWINT - INTEGRA AC2000 Satel Integra alarm interface enables alarms from Integra alarm panels to be fully integrated with the AC2000 access control system. This enables AC2000 to act as the central Security Management System. The interface enables inputs from intruder panels to be placed as icons on the AC2000 AED (Alarm Event Display) application. This provides, on a single screen, a graphical representation of the physical layout of intruder sensors and allows for central alarm monitoring of both access control and intruder alarms.

CEM Systems has released version 5.5 of its core AC2000 SE (Standard Edition) security management system.  Ideal for large to medium sized facilities, AC2000 SE has proven itself as one of the industry's most comprehensive security systems available.  The system offers advanced access control, alarm processing, photo badging and external systems integration.  AC2000 SE also incorporates industry leading CEM hardware and offers clients a comprehensive software suite for administration and advanced reporting. Significant changes include a new graphical user interface for the software splash screens, improved security log-on, enhanced reporting tools and a central overview screen that now allows clients to view alarms across multiple sites.     Benefits at a glanceImproved reporting -Statistics report - report on total number of swipes per device per minutes-Global transactions & alarms report-Automatic report schedulerImproved system security logon -New selectable security policy logon screen with the ability to automatically disable an operator account Single view of alarms from multiple CDC servers -New "global" Alarm Event Display (AED) overview screen to view alarms across all linked CDC serversIncreased system expansion -A single central database server can support up to 176 workstation clientsFor more information email cem.info@tycoint.com To arrange a demo email cem.sales@tycoint.com

CEM CRD/218/004 DESFire 13.56MHz read/write contactless smart card can be used for a range of different applications from access control to other applications such as cashless vending and public transportation. Using a standardised Mifare Application Directory (MAD), the card contains a structured file system offering security for multiple applications and to support future growth. Utilising Triple DES (3DES) encryption, the information is securely stored on the card, ensuring that it cannot be cloned and that only valid cards are granted access.

CEM RDR/D10/100 is a DESFire contactles smart card reader with powerful security and encryption features. It combats against card cloning and Wiegand signal controller cloning. It's three on-board LED indicators to visually confirm/ deny entry.

The multi-functional intelligent access terminal that is revolutionising the security industry emerald from CEM Systems is an intelligent multifunctional IP access terminal that provides more at the door. The first of its kind, emerald is a Touch screen Reader, Door Controller, VoIP Intercom and System Terminal all in a single box. The innovative touch screen LCD greets cardholders by illuminating as they approach, providing a user friendly security experience. emerald’s IP65 rated polycarbonate enclosure and custom LCD touch screen is both dust and water resistant, meaning that it can be used both inside and outside. For enhanced security, emerald offers a keypad for additional PIN verification, and for an added layer of security a scramble keypad can be implemented. Product feature Intelligent Touch Terminal IP Reader & Controller in one - with both functionalities in one device, emerald communicates directly to the AC2000 host server Fully integrated Voice over IP intercom functionality Remote Applications – displaying real time access control information to cardholders Scramble keypad option for Personal Identification Number (PIN)

CEM DCM/300/006 is an intelligent two door board only controller designed to interface third-party read heads with the CEM range of access control systems. It has an on-board 10/100 Ethernet connection and communicates directly with the AC2000 central system. Using a powerful 32bit processor, it gives full off-line validation and decision making capability at the point of entry, when host communication is not available.

CEM SWENETUPG128-256 is an Ethernet reader controller upgrade licence for 128 to 256 doors.

CEM SWENET128 is an Ethernet reader controller software for 128 doors. It is a software controller required for use with Ethernet based CEM readers and devices as part of the AC2000 SE (Standard Edition) and AC2000 AE (Airport Edition) access control systems. The RTC is used with CEM Ethernet devices such as the emerald touch screen reader, S610e reader, S610f reader, Etherprox reader, S3030 portable reader range, eDCM 300 (Door Control Module), eDCM 300 Input/Output Module and the EIOC (Ethernet Input/Output Controller). The RTC Ethernet software offers an added layer of system resilience as it is capable of operating independently from the central CDC server should communications between the two be temporarily lost.

CEM SWENET256 is an Ethernet reader controller software for 256 doors. It is a software controller required for use with Ethernet based CEM readers and devices as part of the AC2000 SE (Standard Edition) and AC2000 AE (Airport Edition) access control systems. The RTC is used with CEM Ethernet devices such as the emerald touch screen reader, S610e reader, S610f reader, Etherprox reader, S3030 portable reader range, eDCM 300 (Door Control Module), eDCM 300 Input/Output Module and the EIOC (Ethernet Input/Output Controller). The RTC Ethernet software offers an added layer of system resilience as it is capable of operating independently from the central CDC server should communications between the two be temporarily lost.

CEM SYS/101/300 is a PC with SWENET256 software installed. The SWENET256 is required for use with Ethernet based CEM readers and devices as part of the AC2000 SE (Standard Edition) and AC2000 AE (Airport Edition) access control systems. The RTC is used with CEM Ethernet devices such as the emerald touch screen reader, S610e reader, S610f reader, Etherprox reader, S3030 portable reader range, eDCM 300 (Door Control Module), eDCM 300 Input/Output Module and the EIOC (Ethernet Input/Output Controller). The RTC Ethernet software offers an added layer of system resilience as it is capable of operating independently from the central CDC server should communications between the two be temporarily lost.

CEM RDR/610/116 PicoPass card reader is designed for use as part of an integrated on-line access control system and is used to control access to restricted areas or in special applications where card activation of machinery is required. It also features large reader database for off-line card verification and alarms.

CEM DCM/300/101 is an intelligent two door controller that also includes enclosure, board & power supply/ battery charger. Using a powerful 32bit processor, it gives full off-line validation and decision making capability at the point of entry, when host communication is not available.

The latest release of the AC2000 suite of access control and security management software. AC2000, AC2000 Airport and AC2000 Lite version 7.0 are now available with a range of new features that increase the performance, simplicity and scope of the system along with a number of additions that improve functionality. Card Validation from online readers AC2000 Users can now validate cards using any online reader, either Ethernet or Serial, without the need to have a dedicated validation reader. AC2000 Intercom CEM AC2000 Intercom software can now be deployed as a standalone installation on dedicated intercom workstations where full AC2000 system functionality is not required. AC2000 now also supports the functionality to record emerald intercom (only available in emerald TS200/TS300 terminals) voice communication to audio files and store on the AC2000 central server. Integrations AC2000 now supports full two way integration with Salto off-line locks utilising SHIP (Salto Host Interface Protocol). This bi-directional interface links directly to the Salto database server. With the release of v7, AC2000 now supports a fully featured interface with Genetec Security Center, a unified platform with IP surveillance. This new link allows alarms and video footage from Genetec Security Center to be fully integrated with AC2000. Enhanced emerald functionality In AC2000 v7 a new pre-door mode allows for the display of a configurable personal message to the cardholder on the emerald terminal. This release also enables system administrators to use AC2000 WEB to upload their company logo to display on the emerald home screen.
