The Hanwha Techwin SNP-6201HN/HP is a 1/3 inch colour / monochrome IP PTZ camera with built-in 20x optical zoom lens. The IP dome camera has 2 MP resolution, intelligent video analytics, face and audio detection, H.264 & MJPEG dual codec, and 360° endless Pan, Tilt/ Zoom.

All models in the Samsung 7002 Professional series are able to capture images at a broad range of resolutions from 320 x 180 to 2048 x 1536 and include Full HD 1080p resolution displayed in 16:9 format. An advanced Wide Dynamic Range (WDR) feature ensures that everything in a scene can be clearly seen, even when images contain both very bright and very dark areas, whilst Progressive Scan technology negates motion blur and ensures sharp edges on moving subjects and vehicles. “The specifications for the new 7002 Professional series take into account the requirements of end-users who want a lot more from a high definition camera other than evidence grade images, and they also reflect the needs of installers,” said Tim Biddulph, IP Product Manager for Samsung Techwin Europe Ltd. “A Simple Focus feature, for example, automatically focuses the camera. All that is needed is one simple push of a button on the back of the camera to achieve optical focus. This will obviously result in reduced installation time. However, there is an additional advantage offered by this very clever feature in that when the camera mode changes from colour to monochrome with the help of the camera’s true Day & Night function, the Simple Focus automatically optimizes the back focus required for clear sharp images.” The 7002 Professional series is supported by many of the leading Video Management Software (VMS platforms as well as Samsung’s Centralized Monitoring Software. Other key features which are common to all models include facial detection and audio detection with the use of an external microphone . Also included is Intelligent Video Analytics which provides Motion Detection, Appear/Disappear, Virtual Line/Enter/Exit detection and a camera tampering alarm function.The new cameras and domes support multi-streaming of video using either H.264 and MJPEG compression and can therefore be simultaneously used for real-time monitoring, mobile monitoring, high quality or high-efficiency recording, SD memory recording and for E-mail notification purposes.“With the launch of the 7002 Professional series and our LiteNet range of  ‘affordable’ megapixel and HD cameras and domes earlier in the year, we can now truly claim to be able to offer customers a high definition  video surveillance solution for virtually any type of project,” said Tim Biddulph. “Customers can also take advantage of the fact that both series are compatible with our recently introduced SRN-1000 network video recorder which has been designed to offer a ‘building block’ approach to the process of specifying a video storage solution.”

Hanwha Techwin SND-5084 from Hanwha Techwin's WiseNetIII network range features most advanced technology with 1.3 megapixel 720p high definition images. Its high end functions include 130dB WDR, low light performance down to 0.05 lux (F1.2, 50IRE, color) creating clear images under low light conditions.

The SND-5061 features 1.3 megapixel and 720p HD resolution at full frame rate, with a compact design. Multiple streaming is possible with a choice of H.264 and MJPEG compression methods, providing the option to simultaneously transmit images to multiple locations at various frame rates up to 30/25 frames per second, and at different resolution.

Samsung Techwin has introduced a firmware upgrade that has dramatically reduced the bandwidth and video storage requirements of the company’s IP network cameras, domes and encoders. “The Samsung Techwin software engineering team has devised some very clever improvements to our version of the H.264 method of compressing images and as a result, a much lower bitrate is required to transmit the high quality images captured by our HD megapixel cameras,” said Tim Biddulph, IP Product Manager for Samsung Techwin Europe Ltd. “Our 3MP Full HD models, for example, previously needed a bit rate of 10Mbps, but now only require 3Mbps to ensure that there are no latency issues or that artefacts do not spoil the quality of the video when customers have configured the cameras to capture images at the highest possible resolution.”  The upgraded firmware, which applies to almost all of Samsung Techwin’s IP network models, can be downloaded free of charge by customers from the product section at www.samsungsecurity.co.uk. “The improvement in the bitrate is in itself a major benefit to our customers because it reduces the amount of bandwidth and storage required to operate an effective video surveillance system,” said Tim Biddulph. “The firmware upgrade however innovatively offers a lot more in terms of transmission efficiency in that it is able to dynamically adjust the transmission bitrate and compression settings depending on the level of activity that may be occurring within a camera’s  field of view. There is little need to transmit very high quality images of an empty building or car park at night, but when however there is activity this needs to be transmitted. Our upgraded firmware automatically takes this into account and adjusts the camera settings accordingly. This results in a much more efficient and effective use of the available bandwidth.”

Hanwha Techwin SND-5083 from Hanwha Techwin's WiseNetIII network range features most advanced technology with 1.3 megapixel 720p high definition images. Its high end functions include 130dB WDR, low light performance down to 0.05 lux (F1.2, 50IRE, color) creating clear images under low light conditions.

Hanwha Techwin SNB-5003 is a 1/3 inch 1.3 megapixel high-defination network camera with enhanced wide dynamic range. The network camera has H.264 & MJPEG dual codec, multi-crop streaming, PoE, 24V AC, 12V DC support and intelligent video analytics.

2 Megapixel (1920 x 1080) resolution 2.8mm fixed lens H.265, H.264, MJPEG codec support, Multiple streaming 60fps@2MP (H.265 / H.264) WDR (120dB) Tampering, Loitering, Directional detection, Fog detection, Audio detection,Digital auto tracking, Heatmap, People counting, Queue  management, Face detection Motion detection,Handover Built-in Analytics Micro SD / SDHC / SDXC memory slot (Maximum 256GB) Hallway View, WiseStream II support LDC, PoE / 12V DC, Bi-directional audio support

Built-in 2.8mm fixed lens • Max. 60fps@all resolutions (H.265 / H.264) H.265, H.264, MJPEG Codec Supported, Multiple streaming WDR (150dB), Defog Loitering, Directional detection, Fog detection, Audio detection, Digital auto tracking, Sound classification, Heatmap, People counting, Queue management, Tampering Motion detection, Handover

Hanwha Techwin  SND-7082F SSDR is to enhance color reproduction and resolution and reduce signal noise. Additional functions include: face detection - prioritizing faces in an image, audio detection - alerting the system to events beyond the camera’s field of view, ROI (Region of Interest) - spotlighting the critical areas in the camera's field of view, and True Day/Night for superior images in the dark.

2 Megapixel (1920 x 1080) resolution 4.44 ~ 142.6mm (Optical 32x) lens IR viewable length : 200m (656ft) Day & Night (ICR), WDR (150dB), DIS (Built-in gyro sensor) Intelligent Video / Audio Analytics, Shock detection Azimuth display (Cardinal & intermediate directions) Multiple streaming, WiseStream II support H.265, H.264, MJPEG codec support MicroSD / SDHC / SDXC memory 2 slots (Up to 512 GB) IP66, IK10, HPoE Injector included, 24VAC

2 Megapixel (1920 x 1080) resolution 2.8mm fixed lens 0.1Lux (Colour), 0Lux (B/W, IR LED on) 30fps@2MP (H.265/H.264) H.265, H.264, MJPEG codec support, Multiple streaming Day & Night (ICR), WDR (120dB) Defocus detection, Directional detection, Motion detection, Enter/Exit, Tampering, Virtual line detection Micro SD / SDHC / SDXC (128GB) memory slot, PoE, 12 V DC IR viewable length 20m IP66, IK10 rated Hallway view, WiseStream II support Analogue video out & simple focus for easy installation LDC support (Lens Distortion Correction)

SCD-2010/2030 mini dome cameras have been designed to generate outstanding images in various installation environments.

5 megapixel resolution 3.9 ~ 9.4mm (2.4x) motorised varifocal lens 0.07Lux@F1.4 (Colour), 0Lux (B/W, IR LED on) 50m IR viewable range for low light/no light monitoring 30fps@5MP (H.265/H.264) H.265, H.264, MJPEG codec supported, multiple streaming Day & Night (ICR), WDR (120dB), Defog Shock detection, Loitering, Directional detection, Fog detection, Audio detection, Digital auto tracking, Sound classification, Tampering Motion detection, Handover, Audio event playback Dual SD/SDHC/SDXC memory slots (Max. 512GB) Hallway view, WiseStream II support, IP67/IP66/IP6K9K, IK10+, NEMA 4X LDC support (Lens Distortion Correction) PoE / 12V DC, Bi-directional audio supportWeathercap included

5 Megapixel (2592 x 1944) resolution 3.2~10mm (3.1x) motorised varifocal lens 0.15Lux (Colour), 0Lux (B/W, IR LED on) 30fps@5MP (H.265/H.264) H.265, H.264, MJPEG codec support, Multiple streaming Day & Night (ICR), WDR (120dB) Defocus detection, Directional detection, Motion detection, Enter/Exit, Tampering, Virtual line detection Micro SD / SDHC / SDXC (128GB) memory slot, PoE IR viewable length 30m IP66, IK10 rated Hallway view, WiseStream II support Analogue video out & simple focus for easy installation LDC support (Lens Distortion Correction)

The 20° tilt on this aluminium mounting solution is designed to maximise effective field of view with wall-mounted fisheye or dome cameras Material: Aluminium Dimensions : Ø160.0 x 57.6mm (6.30" x 2.27") Weight : 325g (0.72 lb) Colour : White Supported products : XNF-9010RV/RVM IP cameras, and XND-9082RV, XND-8082RV, XND-6081RV/6081REV, XND-8081RV/8081REV, PND-A9081RV IP dome cameras

WiseNet III 2MP Full HD network camera range The eight camera models incorporate Samsung’s new WiseNetIII DSP chipset, which has been developed by the company as a result of a market research programme carried out by its worldwide product management team. This identified what users and installers felt were the key ‘must haves’ in order for high definition IP network cameras to automatically become the preferred choice when a new video surveillance system was being specified, or an existing system was being upgraded. The extremely impressive set of features incorporated in to the WiseNet III range include: All of the models can capture high quality images when the lighting level is as low as 0.01 lux. An ultra fast frame rate of 60fps at 1080p which results in latency free clear images. This can be particularly beneficial in a scene with moving subjects by ensuring thatimage edges are kept sharp and clear. Enhanced Wide Dynamic Range which when working with performance greater than 100dB,can accurately produce images in scenes that simultaneously contain very bright and very dark areas. Correct colour is maintained by adopting Regional Adaptive Tone Mapping. Motion blur is reduced by using Samsung’s Motion Artefact Reduction technology. P-iris technology which optimises lens iris control to provide improved depth of field and sharpness. Defogfeature which can be used to help improve the clarity of images captured in poor weather conditions such as rain, snow or fog. Digital Image Stabilization (DIS), previously only seen in analogue chipsets, negates the effects of a camera shaking due to high winds or building vibration. Simple Focus feature which automatically focuses the camera and is built into most of the models. We are certain this will impress installers in terms of the potential to reduce installation and maintenance time, as all that is needed is one simple push of a button on the back of the camera to achieve optical focus. Multi-crop feature enables users to also highlight and crop up to nine areas of interest in order for the camera to only send the images within that area at a preferred resolution and frame rate. Further bandwidth and recording space savings can also be achieved with the help of the third generation of Samsung’s highly acclaimed Super Noise Reduction (SSNR) technology, which eliminates image noise in low light conditions. There is also the option of using Intelligent Video Analytics (IVA) to detect activity by various means, such as face detection, tripwire and enter/exit direction, object appear/disappear and ‘tampering’. Alternatively, the motion detection technology built into the WiseNetIIIDSP chipset can greatly reduce the false alarm rate by learning what is the normal motion of the scene and ignoring, for example, the fluttering leaves on trees. Users can also take advantage of audio detection technology which can further help reduce false alarms by being set up to only react to abnormal sounds.  As is the case with all Samsung professional security products, the cameras in the WiseNetIII range are supplied with full support services from Samsung Techwin Europe Ltd, including free system design, free technical support and a full three-year warranty.

2 megapixel (1920 x 1080) resolution 4.75 ~ 261.4mm (Optical 55x) lens Day & Night (ICR), WDR (120dB) DIS with built-in gyro sensor Maximum IR viewable length: 500m (1,640ft) H.265, H.264, MJPEG codec support Multiple streaming, WiseStream II support Intelligent Video / Audio Analytics, Defog (Optical) microSD / SDHC / SDXC memory 2 slots (Up to 512 GB) IP66, IK10 HPoE / 24V AC Power Input, HPoE injector included

 Max. 4M resolution 2.8 ~ 12mm (4.3x) motorised varifocal lens Max. 20fps@4M resolutions, Max. 30fps@2M resolutions H.265, H.264, MJPEG codec supported, Multiple streaming Day & Night (ICR), WDR (120dB) Motion detection, Tampering, Defocus detection micro SD (128GB) memory slot, PoE / 12V DC IR viewable length 30m, IP66, IK10

The SCD-2022R/2042R are discreet general purpose analog fixed dome cameras suitable for a wide range of applications. It incorporates the 6 the generation Winner engine from Hanwha Techwin that features premium level resolution at 700TV lines in sharp mode and other core functionalities such as SSNRIII, day & night (ICR), and defog.

2 Megapixel (1920 x 1080) resolution 3.2~10mm (3.1x) motorised varifocal lens 0.095Lux (Colour), 0Lux (B/W, IR LED on) 30fps@2MP (H.265/H.264) H.265, H.264, MJPEG codec support, Multiple streaming Day & Night (ICR), WDR (120dB) Defocus detection, Directional detection, Motion detection, Enter/Exit, Tampering, Virtual line detection Micro SD / SDHC / SDXC (128GB) memory slot, PoE, 12 V DC IR viewable length 30m IP66, IK10 rated Hallway view, WiseStream II support Analogue video out & simple focus for easy installation LDC support (Lens Distortion Correction)

Samsung Techwin America continues to expand its WiseNetIII range of high-performance imaging solutions with the SNV-6013 Vandal-Resistant Network Micro-Dome 2 megapixel camera. The SNV-6013 features Samsung’s most advanced imaging technology to deliver 1080p high-definition images at 60fps, even in challenging lighting conditions. The SNV-6013 employs Samsung Super Dynamic Range (SSDR) to produce a wide dynamic range of 120dB, and 50dB signal to noise ratio with Samsung Digital Noise Reduction (SSNRIII). The new camera provides high-quality images in as little as 0.3 lux (F2, 50IRE, color) illumination. Additional features include intelligent video analytics, including tampering, virtual line, enter/exit, appear/disappear and face detection, which can trigger an alarm event (FTP file upload, e-mail notification, etc.) The SNV-6013 supports H.264 (up to 60fps full HD) and MJPEG (up to 30fps) formats and is equipped with a Micro SDX/SDH/SDXC for local recording and storage, ensuring reliable capture of video in the event of a network disruption. It also features video quality adjustment, bitrate control technology, up to 10 streaming profiles, and privacy masking. The SNV-6013 comes with a standard lens with 103.1° horizontal viewing angle, or an optional wide angle lens version with 165° horizontal viewing angle.

Hanwha Techwin SCB-1001 is a 1/3 inch colour / monochrome IP camera with 650 TVL high resolutio. The box camera has super dynamic range, digital noise reduction, privacy masking and coaxial control.

2 Megapixel (1920 x 1080) resolution Built-in 2.8mm fixed lens 0.1Lux (Colour), 0Lux (B/W, IR LED on) 30fps@2MP (H.265/H.264) H.265, H.264, MJPEG codec supported, Multiple streaming Day & Night (ICR), WDR (120dB) Defocus detection, Directional detection, Motion detection, Enter/Exit, Tampering, Virtual line detection Micro SD / SDHC / SDXC (128GB) memory slot, PoE / 12V DC IR viewable length 20m Hallway view, WiseStream II support Analogue video out for easy installation LDC support (Lens Distortion Correction) Built-in microphone

The 20° tilt on this polycarbonite mounting solution is designed to maximise effective field of view with wall mounted fisheye cameras Material : PC Can be used with QNF-8010, QNF-9010 IP cameras Dimensions : Ø99x48.15mm (Φ3.9x1.9") Weight : 100g (0.22 Ib) Colour : White RAL 9003

New Wisenet Multi-sensor Cameras Hanwha Techwin has expanded its Wisenet multi-sensor camera line with Wisenet PNM-7000VD (2-head).  It combines powerful performance at an affordable price. For maximum adaptability, configurable fixed-focus lens/CMOS sensor modules are available in multiple fields of view which can be easily installed onsite. A 2MP lens module is available for the PNM-7000VD, which enables installers to precisely customise the resolution and lens combination for a perfect fit to any environment. The camera brings a new level of quality and value to the multi-directional camera market with high frame-rates, true WDR (Wide Dynamic Range) and a powerful suite of analytics built in. Utilising a single IP address requires only one VMS license, further reducing the cost to install, service and support. The PNM-7000VD camera is a perfect solution for hospitals, schools and retail and allows for individual on-screen displays and a full suite of video analytics including loitering, directional detection, fog detection, tampering, motion detection, object appearing/disappearing and objects entering or exiting an area. Hallway view aspect ratios are also supported for monitoring of vertical shaped areas.
