CEM Security access systems

CEM AC2000 Muster Zones application is used for emergency situations where card holders must congregate in a dedicated ‘safe’ location. The application can be used both in the evacuation of card holders to a location away from the site (or zone) or when necessary it can be used to enable card holder’s to move to a particular safe location within the premises

CEM SYS/102/00F is a CDC failover server which provides the highest level of system resilience.

CEM AC2000 Airport is an access control system that encompasses all the core software features of the powerful AC2000 system with a host of additional functions that have been specifically designed for airports including card charging, authorisers, airport utilities and IATA code. It further features: Highly stable Linux operating system Windows based operator workstations Virtually unlimited expansion Intelligent, multi-technology CEM card readers Seamless integration with external systems; CCTV, intrusion, fire, perimeter detection and more Multi-language support Extensive web-based AC2000 applications

CEM SWFAIL is a failover server software licence.

CEM SWSALTO-32 is a SALTO SALLIS wireless locks licence that supports upto 32 doors. The AC2000 Salto Sallis Wireless Locks integration offers a seamless interface enabling monitor and control of wireless locks within AC2000. The locks are added into the AC2000 system allowing for remote monitoring of alarms and remote door opening.

CEM SWSALTO-64 is a SALTO SALLIS wireless locks licence that supports upto 64 doors. The AC2000 Salto Sallis Wireless Locks integration offers a seamless interface enabling monitor and control of wireless locks within AC2000. The locks are added into the AC2000 system allowing for remote monitoring of alarms and remote door opening.

CEM SWSALTO-192 is a SALTO SALLIS wireless locks licence that supports upto 192 doors. The AC2000 Salto Sallis Wireless Locks integration offers a seamless interface enabling monitor and control of wireless locks within AC2000. The locks are added into the AC2000 system allowing for remote monitoring of alarms and remote door opening.

CEM SWSALTO-16 is a SALTO SALLIS wireless locks licence that supports upto 16 doors. The AC2000 Salto Sallis Wireless Locks integration offers a seamless interface enabling monitor and control of wireless locks within AC2000. The locks are added into the AC2000 system allowing for remote monitoring of alarms and remote door opening.

CEM SWSALTO-256 is a SALTO SALLIS wireless locks licence that supports upto 256 doors. The AC2000 Salto Sallis Wireless Locks integration offers a seamless interface enabling monitor and control of wireless locks within AC2000. The locks are added into the AC2000 system allowing for remote monitoring of alarms and remote door opening.

CEM IOC/310/006 input/output module board provides a flexible means to monitor and control a wide array of external equipment. An addition to the serial suite of devices for use on the CEM AC2000 system, it connects to the 9032/9064 controller. Additionally, it can connect into an Ethernet based system via an ECM (Ethernet Communications Module) unit; if required. It features eight analogue inputs and four outputs that are used to give spare inputs/outputs on the access control system. The four outputs are comprised of two relay contacts and two open drain FET’s acting as switches. The outputs can be used to control a wide variety of equipment including intruder panels, PIR detectors, heating and lighting controls.

CEM IOC/310/101 input/output module includes enclosure, board & power supply/battery charger. The module provides a flexible means to monitor and control a wide array of external equipment. An addition to the serial suite of devices for use on the CEM AC2000 system, it connects to the 9032/9064 controller. Additionally, it can connect into an Ethernet based system via an ECM (Ethernet Communications Module) unit; if required. It features eight analogue inputs and four outputs that are used to give spare inputs/outputs on the access control system. The four outputs are comprised of two relay contacts and two open drain FET’s acting as switches. The outputs can be used to control a wide variety of equipment including intruder panels, PIR detectors, heating and lighting controls.

CEM SWSALTO-128 is a SALTO SALLIS wireless locks licence that supports upto 128 doors. The AC2000 Salto Sallis Wireless Locks integration offers a seamless interface enabling monitor and control of wireless locks within AC2000. The locks are added into the AC2000 system allowing for remote monitoring of alarms and remote door opening.

CEM CEQ/060/100 SMS text messaging module is a turnkey SMS server that empowers the CEM AC2000 range of access control products with the ability to send SMS text messages in the event of an alarm. The ready-to-use solution simply plugs into the Ethernet network and connects to the wireless network via an integrated quad-band GSM modem. This allows quick and easy communication of alarm events to designated mobile cell phones.

CEM IOC/300/101 input/output module includes enclosure, board & power supply/battery charger. The module provides a flexible means to monitor and control a wide array of external equipment. An addition to the Ethernet suite of devices for use on the CEM AC2000 system, it connects to the nearest network point to monitor for example windows or machinery. It features eight analogue inputs and four outputs that are used to give spare inputs/outputs on the access control system. It takes specific inputs and map them to a particular output. This allows functionality such as proximity sensors being used to turn on lights; break glass switches, sounders, releasing door locks etc.

CEM IOC/300/006 input/output module board provides a flexible means to monitor and control a wide array of external equipment. An addition to the Ethernet suite of devices for use on the CEM AC2000 system, it connects to the nearest network point to monitor for example windows or machinery. It features eight analogue inputs and four outputs that are used to give spare inputs/outputs on the access control system. It takes specific inputs and map them to a particular output. This allows functionality such as proximity sensors being used to turn on lights; break glass switches, sounders, releasing door locks etc.

CEM IOC/000/010 is a 64 floors lift control interface that allows seamless control and monitoring of access between elevator floors. Depending on how many floors need controlled, each lift must have a Lift Control Interface (LCI) unit, which is used in conjunction withthe CEM S9032 lift controller.

CEM IOC/000/009 is a 32 floors lift control intreface designed to be an integral component of the AC2000 integrated security management system. It is designed to offer the ability to control the floor access of either one or two lift cabs, each of which can support access to up to 128 floors.

CEM IOC/010/000 is an ethernet input output controller provides a flexible means to monitor and control an array of equipment. It features: Ethernet connectivity to host 16 Inputs (2 or 4 state) 8 Outputs (4 Relay NO/NC and 4 Open Collector) Outputs can be mapped to single or multiple inputs on the same controller or across the network Dedicated tamper input Designed for ease of installation and maintenance using 2 part connectors throughout Backup battery connection for emergency power (optional)

CEM IOC/000/008 is a 16 floors lift control intreface designed to be an integral component of the AC2000 integrated security management system. It is designed to offer the ability to control the floor access of either one or two lift cabs, each of which can support access to up to 128 floors.

CEM ECM/200/000 Ethernet communication module with PSU and enclosure is a serial to Ethernet converter that enables CEM serial communication devices (such as the S600s reader range, InfoProx reader and the DCM controllers), to connect to the AC2000 central system via an Ethernet LAN. The ECM can support a chain of up to 16 RS485 CEM devices connected to a single channel (up to a maximum length of 1.2 km). This provides a cost effective means of connecting a group of serial readers to the AC2000 system from a single Ethernet point.

Authenticate cardholder details anywhere, even if mains power is unavailable Encrypted storage of up to 200,000 cardholders on-board Full colour 3.5” TFT touchscreen LifeSupport hot swappable batteries

CEM DIU/700/200 is a compact door interface unit designed to provide power to a door lock, as well as local power to a CEM reader when a high level of security is required. improves door security, by allowing the installer to locate lock controls on the secure side of a door, with an intelligent CEM reader on the unsecured side.

CEM Systems DIU 230 offers a complete IP based access control solution that eradicates the need to provide local mains power at the door. The unit installation is classed as low voltage and can be completed by IT network installers without the expense of an electrician or electrical contractor.

CEM DIU/700/210 is a compact door interface unit designed to provide power to a door lock, as well as local power to a CEM reader when a high level of security is required. improves door security, by allowing the installer to locate lock controls on the secure side of a door, with an intelligent CEM reader on the unsecured side.

CEM RDR/304/006 portable card reader is a lightweight and rugged hand-held card reading device for use with the CEM AC2000 system v6.3 software & upwards. It can be used for ID card validation at remote sites or temporary entrances which have no power, and can also be used as a mobile device for random checks within pre-defined zones. Up to 200,000 card ID’s can be held in the reader’s database for differentiation between authorised and unauthorised personnel and up to 8,000 offline card swipe transactions can also be stored for on-line transmission to the AC2000 system via built-in 802.11g WiFi connection or USB cabled connection.

CEM DAC/390/032 is a 32 doors intelligent networked device for door entry/exit control and alarm monitoring. It further features: Intelligent embedded network device for access control and alarm monitoring with the CEM AC2000 system Supports up to 32 doors (64 readers IN/OUT) Easy software upgrade to S9064 Controller supporting 64 doors Battery backup available in case of power failure 64 MB compact flash for database with expansion available Storage capacity for up to 250,000 card records TCP/IP based diagnostics/monitoring available via web browser or Telnet Database is retained even in the event of battery backup failure

CEM DAC/390/064 is a 64 doors intelligent networked device for door entry/exit control and alarm monitoring. Feature includes: Intelligent embedded network device for access control and alarm monitoring with the CEM AC2000 system Supports up to 64 doors (128 readers IN/OUT) Battery backup available in case of power failure 64 MB compact flash for database with expansion available Storage capacity for up to 250,000 card records

CEM RDR/304/001 proximity portable card reader is a lightweight and rugged hand-held card reading device for use with the CEM AC2000 system v6.3 software & upwards. It can be used for ID card validation at remote sites or temporary entrances which have no power, and can also be used as a mobile device for random checks within pre-defined zones. Up to 200,000 card ID’s can be held in the reader’s database for differentiation between authorised and unauthorised personnel and up to 8,000 offline card swipe transactions can also be stored for on-line transmission to the AC2000 system via built-in 802.11g WiFi connection or USB cabled connection.
