AV Costar MegaBall G2 Series  (19)

The new MegaBall® G2 offers 1.2, 1080p, 3, and 5 megapixel choices in an all-in-one camera. New adjustable IR LEDs and flush, surface, or bell mount housings. Select motorised P-Iris lens or manual Panomorph 360°.  Advanced options include true day/night, STELLAR™ advanced low-light technology, true WDR at up to 100dB at full resolution. Resolution The MegaBall G2 megapixel camera series fuses optimum performance with outstanding aesthetics. These stylish indoor cameras feature a choice of 1.2-, 1080p-, 3-, or 5-megapixel (MP) resolution options. Challenging lighting conditions Regardless of time-of-day, this camera is ideal for applications with challenging lighting conditions. The series combines a day/night mechanical IR cut filter with an integrated P-iris lens for precise, optimal image quality. For applications with poor lighting conditions optional wide dynamic range is available on some 1080p and 3MP models. For challenging low-light colour images without IR, the 1.2MP STELLAR™, “Spatio Temporal Low Light Architecture” model offers best-in-class light sensitivity capturing details in near complete darkness. For additional low light capabilities Binning Mode is available on 3MP and 5MP camera models. Adjustable infrared illumination MegaBall G2 IR models are integrated with an Adjustable Infrared Illuminator, providing clear images in extreme, low-light scenes. Infrared camera models offer the ability to manually adjust the IR's level of intensity, providing the flexibility to ensure the scene is illuminated uniformly. Ease of installation The camera's interface allows for an intuitive, fast, and easy configuration; while the Free AV IP Utility tool allows users to quickly configure multiple cameras at one time. The MegaBall G2 is ONVIF Profile S (Open Network Video Interface Forum) and PSIA (Physical Security Interoperability Alliance) compliant, providing interoperability between network video products regardless of manufacturer.

Arecont Vision®, the industry leader in IP-based megapixel camera technology, is preparing to deliver the 2nd generation MegaBall® G2 all-in-one indoor day/night H.264 megapixel cameras. STELLAR™ technology The latest MegaBall® G2 Series cameras now deliver STELLAR™ technology for enhanced low light performance. Adjustable IR ensures images always remain clear by allowing users to adjust the angle and intensity of the beam. Images can be scaled to different resolutions to better meet system bandwidth and storage requirements. Another feature of the MegaBall® G2 series is CorridorView™, which allows images to be rotated 90 degrees for increased coverage of hallways and corridors.

Arecont Vision®, the industry leader in IP-based megapixel camera technology, has enhanced the performance of its MegaBall® all-in-one indoor Day/Night H.264 megapixel camera series. The second generation MegaBall® G2 cameras are now equipped with STELLAR™ (Spatio TEmporal Low Light ARchitecture) and Smart IR technologies for enhanced low light performance. The cameras also include CorridorView™ for better coverage in hallways and corridors, the ability to scale images to different resolutions, optional on-board SDMC storage up to 32GB via an SDHC card slot, and a new housing style. MegaBall® G2 cameras are available with 1.2MP, 1080p, 1080p WDR, 3MP, 3MP WDR, and 5MP resolutions.

1/3 inch, True Day / Night, 3 MP, Megapixel, 0, Indoor, Digital (DSP), 12 ~ 48 V DC, 3 ~ 10 mm, H.264 (MPEG-4, Part 10)/Motion JPEG, Back Light Compensation, White Balance, 49, Built-in IR LED, 100Base-T Ethernet, RTSP, RTP/TCP, RTP/UDP, HTTP, DHCP, TFTP, 21 fps, SDHC Card Slot, 6.8 W, -5 ~ +50 C (23 ~ 122 F), 0 ~ 90

1/3 inch, True Day / Night, 3 MP, Megapixel, 0, Indoor, Digital (DSP), Bell mount, 12 ~ 48 V DC, 3 ~ 10 mm, H.264 (MPEG-4, Part 10)/Motion JPEG, Back Light Compensation, White Balance, 45, 100Base-T Ethernet, RTSP, RTP/TCP, RTP/UDP, HTTP, DHCP, TFTP, 21 fps, 6.3 W, -5 ~ +50 C (23 ~ 122 F), 0 ~ 90

1/3 inch, True Day / Night, 1920 x 1080, 0, Indoor, Bell mount, 12 ~ 48 V DC, 3 ~ 10 mm, H.264 (MPEG-4, Part 10)/Motion JPEG, Back Light Compensation, White Balance, 49, Built-in IR LED, 100Base-T Ethernet, RTSP, RTP/TCP, RTP/UDP, HTTP, DHCP, TFTP, 30 fps, 6.8 W, -5 ~ +50 C (23 ~ 122 F), 0 ~ 90

1/3 inch, True Day / Night, 1920 x 1080, 0, Indoor, Digital (DSP), 12 ~ 48 V DC, 3 ~ 10 mm, H.264 (MPEG-4, Part 10)/Motion JPEG, Back Light Compensation, White Balance, 49, Built-in IR LED, 100Base-T Ethernet, RTSP, RTP/TCP, RTP/UDP, HTTP, DHCP, TFTP, 30 fps, SDHC Card Slot, 6.8 W, -5 ~ +50 C (23 ~ 122 F), 0 ~ 90

1/3 inch, True Day / Night, 1920 x 1080, 0, Indoor, Digital (DSP), 12 ~ 48 V DC, 3 ~ 10 mm, H.264 (MPEG-4, Part 10)/Motion JPEG, Back Light Compensation, White Balance, 45 , Built-in IR LED, 100Base-T Ethernet, RTSP, RTP/TCP, RTP/UDP, HTTP, DHCP, TFTP, 30 fps, SDHC Card Slot, 5.9 W, -5 ~ +50 C (23 ~ 122 F), 0 ~ 90

1/3 inch, True Day / Night, 1920 x 1080, 0, Indoor, Digital (DSP), 12 ~ 48 V DC, 3 ~ 10 mm, H.264 (MPEG-4, Part 10)/Motion JPEG, Back Light Compensation, White Balance, 45 , Built-in IR LED, 100Base-T Ethernet, RTSP, RTP/TCP, RTP/UDP, HTTP, DHCP, TFTP, 30 fps, SDHC Card Slot, 5.9 W, -5 ~ +50 C (23 ~ 122 F), 0 ~ 90

1/3 inch, True Day / Night, 1920 x 1080, 0, Indoor, Digital (DSP), Bell mount, 12 ~ 48 V DC, 3 ~ 10 mm, H.264 (MPEG-4, Part 10)/Motion JPEG, Back Light Compensation, White Balance, 45 , 100Base-T Ethernet, RTSP, RTP/TCP, RTP/UDP, HTTP, DHCP, TFTP, 30 fps, 5.9 W, -5 ~ +50 C (23 ~ 122 F), 0 ~ 90

1/3 inch, True Day / Night, 3 MP, Megapixel, 0, Indoor, Digital (DSP), 12 ~ 48 V DC, 2.8 ~ 8.5 mm, H.264 / MJPEG, Back Light Compensation, 100Base-T Ethernet Network Interface, RTSP, RTP/TCP, RTP/UDP, HTTP, DHCP, TFTP, IPv4, IPv6, QoS, 21 fps, 8.1 W, 100 x 87, 520, -5 ~ +50 C (23 ~ 122 F), 0 ~ 90

1/2 inch, True Day / Night, 5 MP, Megapixel, 0, Indoor, Digital (DSP), 12 ~ 48 V DC, 3.4 ~ 10 mm, H.264, Back Light Compensation, White Balance, Built-in IR LED, 100Base-T Ethernet, RTSP, RTP/TCP, RTP/UDP, HTTP, DHCP, TFTP, 64, SDHC card slot, 6.3 W, -5 ~ +50 C (23 ~ 122 F), 0 ~ 90

1/2 inch, True Day / Night, 5 MP, Megapixel, 0, Indoor, Digital (DSP), 12 ~ 48 V DC, 3.4 ~ 10 mm, H.264, Back Light Compensation, White Balance, Built-in IR LED, 100Base-T Ethernet, RTSP, RTP/TCP, RTP/UDP, HTTP, DHCP, TFTP, 34 fps, SDHC Card Slot, 5.7 W, -5 ~ +50 C (23 ~ 122 F), 0 ~ 90

1/3 inch, True Day / Night, 3 MP, Megapixel, 0.3, Indoor, Digital (DSP), Bell Mount mount, 12 ~ 48 V DC, 3 ~ 10 mm, H.264, Back Light Compensation, White Balance, 100Base-T Ethernet, RTSP, RTP/TCP, RTP/UDP, HTTP, DHCP, TFTP, 21 fps, 6.8 W

1/3 inch, True Day / Night, 3 MP, Megapixel, 0.3, Indoor, Digital (DSP), 12 ~ 48 V DC, 3 ~ 10 mm, H.264, Back Light Compensation, White Balance, Built-in IR LED, 100Base-T Ethernet, RTSP, RTP/TCP, RTP/UDP, HTTP, DHCP, TFTP, 21 fps, SDHC card slot, 6.8 W, -5 ~ +50 C (23 ~ 122 F), 0 ~ 90

1/3 inch, True Day / Night, 5MP resolution, Digital (DSP), Megapixel, 0, 12 ~ 48 V DC, Motion Activated, 3.4 ~ 10, Flush, Surface, Wide Dynamic Range, 2592 x 1944, 14 fps, Back Light Compensation, White Balance, 45, Zoom, H.264 (MPEG-4, Part 10)/Motion JPEG, 100Base-T, RTSP, RTP/TCP, RTP/UDP, HTTP, DHCP, TFTP, 6.3 W, 540, 130 x 98, -5 ~ +50 C (-23 ~ +122 F), 0 ~ 90

1/3 inch, True Day / Night, 3MP resolution, Digital (DSP), Megapixel, 0, 12 ~ 48 V DC, Motion Activated, 3 ~ 10, Flush, Surface, Wide Dynamic Range, 2048 x 1536, 21 fps, Back Light Compensation, White Balance, 49, Zoom, H.264 (MPEG-4, Part 10)/Motion JPEG, 100Base-T, RTSP, RTP/TCP, RTP/UDP, HTTP, DHCP, TFTP, 6.8 W, 540, 130 x 98, -5 ~ +50 C (-23 ~ +122 F), 0 ~ 90

1/3 inch, True Day / Night, 3MP resolution, Digital (DSP), Megapixel, 0, 12 ~ 48 V DC, Motion Activated, 3 ~ 10, Flush, Surface, 2048 x 1536, 21 fps, Back Light Compensation, White Balance, 45, Zoom, H.264 (MPEG-4, Part 10)/Motion JPEG, 100Base-T, RTSP, RTP/TCP, RTP/UDP, HTTP, DHCP, TFTP, 6.3 W, 540, 130 x 98, -5 ~ +50 C (-23 ~ +122 F), 0 ~ 90

1/3 inch, True Day / Night, 1080p resolution, Digital (DSP), Network, 0, 12 ~ 48 V DC, Motion Activated, 3 ~ 10, Flush, Surface, Wide Dynamic Range, 1920 x 1080, 30 fps, Back Light Compensation, White Balance, 49, Zoom, H.264 (MPEG-4, Part 10)/Motion JPEG, 100Base-T, RTSP, RTP/TCP, RTP/UDP, HTTP, DHCP, TFTP, 6.8 W, 540, 130 x 98, -5 ~ +50 C (-23 ~ +122 F), 0 ~ 90, HD
