Lilin MR6822E2 1080P Day & Night Fixed IR IP Mini Dome Camera

Technical Specification

Features:

Make: LILIN
Model code: MR6822E2
Colour Type: Colour / Monochrome
Resolution TVL: 1080p
Megapixel: Yes

Additional info:

Full HD 2 megapixel CMOS image sensor 1080P True H.264 AVC High Profile video compression H.264 and Motion JPEG multi-profile video streaming Smart H.264 supported 3D noise reduction (MCTF) 2D WDR function HDR function up to 100dB Digital PTZ supported IVS supported Tampering / Motion detection alarm function High efficiency IR LED, radiant distance up to 30m Day & Night (IR cut removable) Built-in highly sensitive microphone ONVIF Profile S supported IP67 rain and dust resistant

Contact manufacturer Contact manufacturer Datasheet Datasheet

Make	LILIN
Manufacturer	LILIN
Category	CCTV>IP Dome cameras
Model code	MR6822E2
Colour Type	Colour / Monochrome
Resolution TVL	1080p
Megapixel	Yes
Sensitivity lux	0.02
Indoor/Outdoor	Indoor/Outdoor
Digital (DSP)	Yes
Mount Type	Wall mount
Electrical Specifications	Voltage: 12 V DC, PoE Power Consumption: 4.5W
Focal length	4mm
Compression	H.264 main and high profile, Motion JPEG
Auto Gain Control	Yes
White Balance	Yes
Electronic Shutter range	1/30(1/25)s – 1/30000s
S/ N (Signal/ Noise) Ratio dB	> 50
Network Properties	Interface: 10/100 Mbps Base-T (Tx), RJ-45 Network Protocols: IPv4, IPv6, TCP, UDP, HTTP, HTTPS, SMTP, MQTT, QoS, SNMP, SNMP Trap, NTP, DDNS, UPnP, FTP, ARP, DHCP, PPPoE, DNS, RTSP, RTCP, Telnet, ICMP, IGMP, ONVIF Profile S, SDDP, Bonjour, 802.1x, SSL/TLS Image Frame Rate: 30 fps
Physical Specifications	Dimensions mm: Ø 73 × 62 Weight g: 230
Environmental Specifications	Operating Temp ^oC: -40 ~ +50 C (-40 ~ +122 F) Operating Humidity %: 0 ~ 90
System Requirements	Operating System: Windows 7 or above Web Browser: Microsoft® Internet Explorer® 9 or above
Additional info	Full HD 2 megapixel CMOS image sensor 1080P True H.264 AVC High Profile video compression H.264 and Motion JPEG multi-profile video streaming Smart H.264 supported 3D noise reduction (MCTF) 2D WDR function HDR function up to 100dB Digital PTZ supported IVS supported Tampering / Motion detection alarm function High efficiency IR LED, radiant distance up to 30m Day & Night (IR cut removable) Built-in highly sensitive microphone ONVIF Profile S supported IP67 rain and dust resistant
