Iluminar WL643-10-PoE-2 Super long range White Light illuminator

Technical Specification

Features:

Make: Iluminar
Model code: WL643-10-PoE-2
Series: Iluminar - WL643-PoE-2 Series
LED Type: White
Distance: 196 m illumination range

Additional info:

Super long range White Light illuminator Visible light for color SMT LED technology Distances up to 643’ (196m) Angles 10deg, 30deg, 60deg, 100deg & 120deg Low power consumption (48W) Long life 5 year warranty IP67 weatherproof rating Built-in photocell on/off Telemetry input for remote switching High PoE power

Contact manufacturer Contact manufacturer Datasheet Datasheet

Make	Iluminar
Manufacturer	Iluminar Inc.
Category	CCTV>CCTV camera lighting
Model code	WL643-10-PoE-2
Series	Iluminar - WL643-PoE-2 Series
LED Type	White
Distance	196 m illumination range
Photocell	Yes
Physical Specifications	Dimensions mm: 210 x 110 x 80 Weight kg: 2000
Electrical Specifications	Voltage: High Power PoE Power Consumption: 52W
Environmental Specifications	Operating Temperature ^oC: -50 ~ +60 C (-58 ~ +140 F) Protection: IP67
Additional info	Super long range White Light illuminator Visible light for color SMT LED technology Distances up to 643’ (196m) Angles 10deg, 30deg, 60deg, 100deg & 120deg Low power consumption (48W) Long life 5 year warranty IP67 weatherproof rating Built-in photocell on/off Telemetry input for remote switching High PoE power
