Hikvision DS-2CD2087G2H-LI(U) IP camera Specifications

Hikvision upgrades ColorVu technology for better night vision experience

Product Profile

Hikvision enhances ColorVu, its high quality full-color technology, with Super Confocal and Smart Hybrid Light technologies. With these enhanced ColorVu offerings, even sharper imaging is made possible, with precise focusing in ultra-low light and flexible “hybrid” lighting modes to fit the scenario.

“By upgrading ColorVu technology, we aim to elevate our customers’ night vision experience in any setting with always-sharply-focused imaging and versatile lighting options,” says Rubio Hong, the Product Director at Hikvision, “We are very proud of our ultra-low-light technology, which eliminates the headache of darkness and unclear footage.”

Improved low-light imaging performance with the Super Confocal Technology

Hikvision’s industry-leading ColorVu technology provides full-color footage 24 hours a day, so users see the same sharply rendered images at night as they would see in broad daylight. Now boosted by Super Confocal Technology, ColorVu’s performance in low lighting gets even more stable and precise.

As infrared light focuses differently than visible light, it’s very difficult for dual-light cameras to create sharp images in low light. Given that cameras with ColorVu are equipped with large-aperture, high-resolution lenses, the focus depth is too small for the frame, which makes infrared imaging even more difficult.

But now, to solve this problem, Hikvision has infused Super Confocal Technology. This is a high-caliber-lens design which reduces optical light dispersion to ensure that the point of focus on the sensor for the infrared light is virtually the same as that of the visible light (thus, “con”-focal). Focusing both types of light at the same spot helps prevent blur and improves the user’s viewing experience by rendering clear, vivid images both in color and black-white. Achieving confocal imaging with F1.0 super aperture is also an industry-first.

Flexible lighting options with the Smart Hybrid Light technology

Hikvision’s Smart Hybrid Light technology can automatically switch from IR light to visible white (supplemental) lighting at night. Equipped with this technology, cameras offer three supplemental lighting options to suit a user’s unique nighttime scenario, depending on the need. The white or visible light mode establishes color imaging; the IR mode (invisible to humans) enables continual black-and-white imaging at night with no light pollution; and the “smart” mode enables the light to automatically change between the two modes based on perimeter events.

With the smart mode turned on, the camera maintains infrared illumination at night until an event triggers color imaging to capture critical details. This means that once human or vehicle motion is detected by the camera, it switches to regular lights and turns to full color. This helps in two critical ways: first, the camera’s color imaging captures better footage which can be used to identify the intruder. Secondly, the triggered light acts as a deterrent to would-be trespassers who might potentially get startled and flee the scene.

Great potential for use in both indoor and outdoor applications

Recording “no action” footage at night or in poorly lit areas with infrared mode, the cameras’ location won’t be given away, and the chance of a camera being seen and vandalized by intruders is vastly reduced. On the other hand, a bright light triggered by a security event and flooding the area helps deter intruders while recording with the same vibrant, colorful images as in daylight.

Therefore, cameras with ColorVu are ideal for both indoor and outdoor scenarios, such as warehouses, retail stores, public parks, and residential settings, where little or no movement is expected at night but discretion is desired for security cameras. Smart, automated lighting options combined with extremely accurate and sharply-focused details creates a camera that truly goes above and beyond current security industry expectations and performance.

Contact manufacturer Contact manufacturer Datasheet Datasheet

Make	Hikvision
Manufacturer	Hikvision
Category	CCTV>IP cameras
Model code	DS-2CD2087G2H-LI(U)
Chip Inch Size	1/1.8 inch
Colour Type	Colour / Monochrome
Resolution	8 MP resolution
Sensitivity Lux	Colour: 0.0005 Lux @ (F1.0, AGC ON),0 Lux with light
Electrical Specifications	Voltage: 12 V DC, PoE
Focal Length mm	2.8 mm / 4 mm
Wide Dynamic Range	Yes
Back Light Compensation	Yes
Auto Gain Control	Yes
White Balance	Yes
Electronic Shutter Range	1/3 s to 1/100,000 s
S/ N (Signal/ Noise) Ratio dB	≥ 52
Mini or Compact	Yes
Compression Type	Main stream: H.265/H.264/H.264+/H.265+, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264, *Third stream is supported under certain settings.
Network Properties	Interface: RJ45 10 M/100 M self-adaptive Ethernet port Network Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP
Physical Specifications	Dimensions mm: Ø74.4 x 179.2 Weight g: 525
Environmental Specifications	Protection: IP67 Operating Temperature ^oC: -30 ~ +60 C (-22 ~ +140 F) Operating Humidity %: <95
System Requirements	Web Browser: Plug-in required live view: IE 10, IE 11, Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
Additional info	High quality imaging with 8 MP resolution Smart Dual-Light: advanced technology with long range Clear imaging against strong back light due to 130 dB WDR technology Efficient H.265+ compression technology Focus on human and vehicle classification based on deep learning -U: Built-in microphone for real-time audio security Water and dust resistant (IP67)
