HID Vertx V300 Access control controller

Technical Specification

Please note: this is a discontinued product.

Go to Replacement product

HID Vertx V300 Access control controller

Features:

Make: HID
Model code: Vertx V300
Series: VertX
Networkable: Yes
Onboard No/Type of Inputs / Outputs: 2 auxiliary inputs, 12 relay outputs

Additional info:

The V300 output control interface contains 12 latching Form-C relays, which can connect up to 12 devices controllable by simple contact closures, such as logic inputs for process equipment, HVAC and elevator control panels, CCTV switchers, etc. Loads exceeding 2 A @ 30 VDC should be controlled via interposing relays.

Contact manufacturer Contact manufacturer Datasheet Datasheet

Make	HID
Manufacturer	HID
Category	Access Control>Access control controllers
Model code	Vertx V300
Networkable	Yes
Onboard No/Type of Inputs / Outputs	2 auxiliary inputs, 12 relay outputs
Universal / Wiegand Reader Interface	Yes
Electrical Specifications	Voltage: 9 ~ 18 V DC Power Consumption: 60 mA
Physical Specifications	Dimensions mm: 147.32 x 122.55 x 32.38 Weight g: 350
Environmental Specifications	Operating Temp ^oC: 0 ~ 50 Operating Humidity %: 5 ~ 95
Accessories	Output control interface
Additional info	The V300 output control interface contains 12 latching Form-C relays, which can connect up to 12 devices controllable by simple contact closures, such as logic inputs for process equipment, HVAC and elevator control panels, CCTV switchers, etc. Loads exceeding 2 A @ 30 VDC should be controlled via interposing relays.
