Hanwha Techwin Wisenet 7
Product Profile
With its own device certificate issuing system, Root CA, the Wisenet camera lineup offers the highest levels of cybersecurity possible. Secure by Default, Hanwha Techwin’s cybersecurity policy, embeds unique certificates into all products during each step of the development and manufacturing process. This results in a cybersecurity policy that satisfies stringent UL CAP standards as well as our own requirements for product reliability and design innovation.
Technical Specification
| Make | Hanwha Vision |
|---|---|
| Manufacturer | Hanwha Vision Europe (formerly Hanwha Techwin Europe) |
| Category | CCTV>IP Dome cameras |
| Model code | XNV-9082R |
| Series | Wisenet 7 |
| Chip Inch Size | 1/2.8 inch |
| Colour Type | Colour / Monochrome |
| Resolution TVL | 4K resolution (3840x2160) |
| HD | Yes |
| Megapixel | Yes |
| Sensitivity lux | 0 ~ 0.05 |
| Dome Type | PTZ |
| Indoor/Outdoor | Indoor/Outdoor |
| Digital (DSP) | Yes |
| Electrical Specifications |
Voltage: 12 V DC / 24 V AC / PoE Power Consumption: 11.5 W |
| Focal length | 2.8 ~ 8.4 mm |
| Compression | H.265/H.264: Main/High, MJPEG |
| Back Light Compensation | Yes |
| Auto Gain Control | Yes |
| White Balance | Yes |
| Electronic Shutter range | 1/5 ~ 1/12,000sec |
| Built-in IR LED | Yes |
| Video Output | CVBS: 1.0 Vp-p / 75Ω composite |
| Zoom Ratio | x3 |
| Network Properties |
Interface: RJ-45(10/100/1000BASE-T) Network Protocols: IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP (TCP, UDP Unicast) Image Frame Rate: 30 fps |
| Physical Specifications |
Dimensions mm: Ø180 x 125 Weight g: 1,900 |
| Environmental Specifications |
Operating Temp oC: -50 ~ +60 C (-58 ~ +140 F) Operating Humidity %: 0 ~ 95 Protection: IP66/IP67/IP6K9K, IK10+ |
| Additional info |
|
| Download PDF version Download PDF version | |
