ReX — Intelligent radio signal range extender

Product Profile

ReX expands the boundaries of the protected area. The range extender controls the system devices connected to it enabling the user to place them at a considerable distance from the hub — in a high-rise office, in a detached garage or in a large production plant — while maintaining a stable connection.

ReX acts as a reliable link between the hub and Ajax devices. Depending on the requirements, all detectors or only some of them can operate via the intelligent range extender.

While regular range extenders represent the weakest link in the security systems increasing the risk of losing the alarm signal during transmission, ReX takes the reliability and resilience of Ajax to a new level. After the hub, ReX is the second decision-making center. It integrates detectors into an autonomous group within the system. If the connection with the hub is interrupted for some reason, ReX will assume control: it will receive an alarm signal from the detector and activate the siren to attract attention to the incident and scare off the burglar.

Read more

Technical Specification

Make Ajax
Manufacturer Ajax Systems
Category Intruder Alarms>Intruder alarm accessories
Model code ReX
Electrical Specifications Voltage: 110 ~ 240 V AC
Physical Specifications Dimensions mm: 163 х 163 х 36
Environmental Specifications OperatingTemp oC: -10 ~ +40 C (14 ~ 104 F)
Protection: IP20
Additional info
  • Provides a two-way connection via secure Jeweller protocol at a distance of up to 1800 m from the hub
  • Combines devices into an autonomous group and manages their communication. If there is no connection to the hub for some reason, and the detector registers an intrusion, ReX will receive an alarm and turn on the siren to draw attention to the incident
  • An alarm is transmitted within 0.3 s.
  • The tamper button protects from detaching ReX from the surface or removing the mounting panel. Block cipher encryption of data, frequency hopping, and device authentication during each contact prevent forgery of the equipment and signals
  • Hassle-free installation and setup
