Dahua Technology VTO2301R-P IP villa door station

Technical Specification

Features:

Make: Dahua Technology
Model code: VTO2301R-P
Type of Kit/ System: Video & Audio
Mount Type: Surface Mount
No of Call Buttons on Panel: 1 call buttons

Additional info:

Ultra slim design PC and ABS material make it ideal for indoor and outdoor use 1/2.8" 2-MP HD CMOS camera Offers two–way video call with indoor monitors Video and voice messages from visitors can be checked on the indoor monitor Video call and unlocking through app IR illumination and auto WDR IP65 rated H.264 and H.265 PoE power supply

Contact manufacturer Contact manufacturer Datasheet Datasheet

Make	Dahua Technology
Manufacturer	Dahua Technology Ltd
Category	Access Control>Audio, video or keypad entry
Model code	VTO2301R-P
Type of Kit/ System	Video & Audio
Mount Type	Surface Mount
No of Call Buttons on Panel	1 call buttons
Panel Material	PC and ABS
Panel Colour	Light Grey
Fixed Camera	Yes
Environmental Specifications	Operating Temperature ^oC: -40 ~ 60 C (-40 ~ 140 F) Operating Humidity %: 10 ~ 90 Protection: IP65
Electrical Specifications	Voltage: 12 ~ 33 V DC, PoE Power Consumption: < 5.5 W
Physical Specifications	Dimensions mm: 160 x 50 x 30 Weight g: 170
Additional info	Ultra slim design PC and ABS material make it ideal for indoor and outdoor use 1/2.8" 2-MP HD CMOS camera Offers two–way video call with indoor monitors Video and voice messages from visitors can be checked on the indoor monitor Video call and unlocking through app IR illumination and auto WDR IP65 rated H.264 and H.265 PoE power supply
Download PDF version Download PDF version
