Anviz 8MP AI-Powered Mini Dome Network Camera with 360° Clarity

Product Profile

High-Resolution Imaging

The iCam D28F features an 8-megapixel resolution, providing sharp and clear visuals. It is designed to capture a clear spherical view, offering 180° or 360° panoramic angles, which enhances its coverage and effectiveness.

Advanced Technology

Equipped with deep learning AI algorithms, the iCam D28F enhances performance through sophisticated analysis. Its HDR wide dynamic range technology and large-aperture lens ensure that true color and detailed display are maintained, even in low light or near darkness, allowing for high-quality imaging in various conditions.

Compact and Discreet Design

The camera boasts a compact and sleek design, making it barely noticeable once installed. This discreet appearance allows it to blend seamlessly into indoor environments.

Two-Way Communication

The iCam D28F is equipped with a built-in microphone and speaker, enabling real-time audio communication. This feature supports interactive surveillance and immediate response capabilities.

Enhanced Surveillance Capabilities

Smart Detection Features

The camera can automatically detect and classify humans, vehicles, and moving objects. This capability facilitates perimeter intrusion and loitering detection, as well as other behavioral analyses, improving overall security management.

Event Alerts and Cloud Storage

When an abnormal event is detected, users receive alerts through the IntelliSight mobile app. Additionally, event recordings can be viewed in the cloud, providing convenient access to important footage. The iCam D28F also supports the insertion of a 128GB micro SD card, allowing for over two weeks of continuous video storage, ensuring extensive and reliable recording capability.

Read more

Technical Specification

Make Anviz
Manufacturer Anviz Global Inc.
Category CCTV>IP Dome cameras
Model code iCam-D28F
Chip Inch Size 1/1.8 inch
Colour Type Colour / Monochrome
Resolution TVL 8MP/4K
HD Yes
Megapixel Yes
Sensitivity lux Colour: 0.01Lux @(F1.2, AGC ON)
Indoor/Outdoor Indoor
Mount Type Wall, Ceiling mount
Electrical Specifications Voltage: 12 V DC, PoE
Power Consumption: <6W
Focal length 1.7 mm
Compression H.264, H.265
Back Light Compensation Yes
Auto Gain Control Yes
White Balance Yes
Electronic Shutter range 1/12s ~ 1/10000s
S/ N (Signal/ Noise) Ratio dB 39dB
Network Properties Interface: RJ45 (10/100Mbps)
Network Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, IPv4, IPv6
Physical Specifications Dimensions mm: Φ100.4 x 41
Weight g: 380
Environmental Specifications Operating Temp oC: -10 ~ +50 C (14 ~ 122 F)
Operating Humidity %: 10 ~ 90
Additional info
  • High Definition up to 8MP
  • Fisheye Design
  • Built-in Microphone
  • Smart Events
  • Edge Deep Learning Engine
